BLASER 1-7X28 IC SCOPE
Everything in Sight
IVD – Intelligent Variable Dot
TRUE 1x MAGNIFICATION
Only with both eyes open, the shooters peripheral vision can truly track game ensuring a safe shot. The Blaser 1–7x28 iC offers this benefit thanks to its true 1x magnification. Ideal for optimum overview and rapid target acquisition.
Blaser 1–7x28 iC
The comfortable eye relief of 90 mm minimizes the risk of recoil induced eye injuries on big bore rifles. The intelligent Variable Dot IVD is an invaluable assistance in hunting for strongly self-protective game which requires instant target acquisition when approaching quickly. Thanks to the 28 mm objective lens the 1–7x28 iC is perfectly usable even in twilight, which makes it a versatile riflescope for worldwide hunting on all seven continents.
IVD (Intelligent Variable Dot), automatically activated illuminated dot for driven hunts
True 1x magnification
Very large field of view of more than 40 m
Large exit pupil of 10 mm with 1x for rapid target acquisition
Large zoom range for universal use
28 mm lens diameter enables a 7x magnification with an exit pupil of 4 mm. This enhances the field of application with poor lighting conditions.
TECHNICAL SPECIFICATIONS
Blaser 1–7x28 iC
Magnification
1x – 7x
Effective lens diameter
10 mm – 28 mm (0.39 " – 1.1 ")
Exit pupil diameter
10 mm – 4 mm (0.39 " – 0.16 ")
Field of view at 100 m (109 yds)
40,8 m – 6,0 m (44.6 yds – 6.6 yds)
Eye relief
90 mm (3.5 ")
Transmission
> 90% night
Parallax compensation
100 m (109 yds) fixed
Elevation adjustment at 100 m (109 yds)
180 cm (1.97 yds)
Windage adjustment at 100 m (109 yds)
180 cm (1.97 yds)
Adjustment per click
1 cm / 100 m (0.39 " / 109 yds)
BLASER 2.8-20X50 IC SCOPE
BLASER 4-20X58 IC SCOPE
BLASER 4-20X58 IC
POWERFUL LIGHT RESERVE
58 mm OBJECTIVE LENS DIAMETER
Compared to riflescopes featuring a 56 mm objective lens diameter, 58 mm provide an additional light yield of 7%. This allows use of a higher magnification with better detail recognition in deep twilight or at night.
Blaser 4–20x58 iC
The twilight specialist – superior for sitting game and when hunting in the very last light. Excellent light gathering characteristics far exceed what other scopes provide in low light conditions. Making the impossible long range shot possible.
High contrast and optimal sharpness of detail, especially in the last light
58 mm lens diameter means more than 7% additional light yield compared to a 56 mm lens
20x magnification provides invaluable services to safely identify game and gives the ability to interpret and understand targets at long range.
TECHNICAL SPECIFICATIONS
Blaser 4–20x58 iC
Magnification
4 x – 20 x
Effective lens diameter
49 mm – 58 mm (1.93 " – 2.28 ")
Exit pupil diameter
12.3 mm – 2.9 mm (0.48 " – 0.11 ")
Field of view at 100 m (109 yds)
9.2 m – 1.9 m (10.0 yds – 2.0 yds)
Eye relief
90 mm (3.5 ")
Transmission
> 90% night
Parallax compensation
50 m (54.7 yds) to infinity,100 m (109 yds) arresting
Elevation adjustment at 100 m (109 yds)
±75 cm (0.82 yds)
Elevation adjustment with QDC at 100 m
80 cm (31.5 ")*
Windage adjustment at 100 m (109 yds)
±50 cm (19.68 ")
Adjustment per click
1 cm / 100 m (0.39 " / 109 yds)
Weight
770 g (31.22 oz)
Overall length
365 mm (14.37 ")
BLASER B2 2.5-15X56 IC
EVERYTHING YOU NEED IN A RIFLESCOPE.
THE NEW BLASER B2 OPTICS FOR
DAY AND NIGHT HUNTING.
MADE BY BLASER.
MADE IN GERMANY.
OPTIMISED FOR NIGHT TIME HUNTING.
Designed from the ground up for the use with clip-on technology, the Blaser
B2 riflescopes have undergone the same shock resistance tests that are
standard for testing premium riflescopes – and all B2 models passed with
flying colours
With an overall length that is up to four centimetres shorter than
comparable scopes, the Blaser B2 riflescopes are extremely compact.
When hunting, this short overall length ensures that a clip-on device can be
comfortably operated from the shooting position and that the rifle’s centre
of gravity is not shifted forward unnecessarily. Another advantage of the
compact design is the short range of motion of the zoom system’s movable
lenses which results in improved mechanical precision and a more stable
point of impact when changing magnification. At the same time, the
mechanical robustness compensates for the additional stress on the scope
when shooting with a clip-on device.
In combination with the easy-to-mount, absolutely repeatable attachment
mounts and the corresponding clip-on device, the Blaser B2 riflescopes
become true night hunting specialists.
HAWKE AIRMAX 3-12X50 AMX IR
The Hawke Airmax 30 SF family of scopes focusses on long and short range Airgun hunting and Airgun Target shooting.
Designed in the UK, the New Airmax 30 SF family provides the shooter a feature-rich scope. The exciting new cosmetic for the Airmax 30 family is just the start of the innovation. New locking resettable turrets make adjustments easy and repeatable, even when used with gloved hands. Boasting a stepless rheostat control that allows for virtually infinite adjustment, ensuring your reticle is visible in almost any light condition.
The new Airmax 30 SF scopes are equipped with a side focus parallax adjustment, with a range of 10 yards to infinity. This enables the shooter to be parallax free and in focus at all target distances. The Patented design allows for the addition of a larger wheel (100mm dia. wheel supplied) to be installed direct to the central axis. This allows for easier, more accurate operation (Pat App # 1320436.7).
Built around a 30mm mono-tube chassis, the Airmax 30 SF scopes are designed to provide years of reliable use. Four magnification ranges (3-12, 4-16, 6-24 and 8-32) mean no compromising when it comes to scope selection.
All Hawke Airmax 30 SF scopes have lenses that are fully multicoated for the best possible light transmission and management. Waterproof, shockproof, and nitrogen purged to be fog proof; all Airmax 30 SF scopes are covered by the Hawke Worldwide Warranty (10 years in Europe and ROW).
Airmax 30 Side Focus Large Side Wheel
One truly exceptional feature of the new Airmax 30 SF scopes is the new AMX airgun reticle available for the first time in this scope family.
Based on a fully floating Mil Dot with additional half milspacing marks below centre, windage marks as well as segmented hollow posts, the reticle is perfectly suited for airgun shooting. Fully BRC/Chairgun Pro compatible, the AMX is an efficient, reliable reticle, that any airgun hunter or target shooter can appreciate.
Additionally, the Airmax AMX reticles are supported by the free Hawke BRC and Chairgun software programs (PC, Mac, iOS and Android). Supported by your true ballistic information, the BRC allows you to blueprint your projectile to any Hawke multiple aim point reticle
Key Features:
" 30mm Mono-tube design - handles heavy recoil
" Side Focus Parallax adjustment
" Additional 100mm large focus/parallax wheel*
" Fully multi-coated optical system for maximum clarity & light transmission
" Glass etched illuminated reticles - never lose the aim point
" Infinitely adjustable stepless rotary switch
" ¼ M.O.A locking resettable positive click turrets
" Coil erector spring - no shift in zero
Additional Features:
" Protective lens caps
" Tactile high performance rubber grip zoom CRD # 002 343 939
" Fast focus ocular, set the dioptre in seconds
" Fully removable screw-in metal flip-open lens covers
" Sunshade compatible (all models supplied with sunshade)
" Waterproof, shock proof, all calibre rated
" Nitrogen purged & fog proof, for use in all conditions
" Hawke Worldwide warranty
HAWKE AIRMAX 30 4-16X50 FFP
Airguns can have a devastating effect on optics if the right products aren’t used. Hawke is an industry leader in developing specialised optics for serious airgun shooters and hunters. All 30mm tube models have Side Focus parallax adjustment that can focus down to 10 yards/9 metres and have additional Side Focus wheels supplied in the box. Illuminated reticules maximise visibility in dark cover and brush.
• First Focal Plane optical system • Wide Angle optical system ideal for varmint/airgun • 16 layer fully multi-coated optics for exceptional clarity • Side focus control for parallax adjustment to infinity • 30mm mono-tube chassis for superior strength • Glass etched reticule with red illumination • 6 levels of brightness with off positions in-between • 1⁄10 MRAD capped, resettable target turrets • Fast focus eyebell and high torque zoom ring FFP AMX IR RETICLE The FFP AMX IR was developed specifically for first focal plane optical systems and based around the common principles of mil spaced reticules. The FFP AMX IR offers multiple aim points, useful when shooting at longer distances. Half Mil Dot spacing on the lower post provides increased aim points for long shots. The horizontal bars are positioned at 0.5, 1.5, 2.5, 3.5 and 4.5 Mil spacing. Hollow posts are segmented into Mil spacing and can be used for bracketing. The mil spaced reticle and 1⁄10 MRAD turrets make for easy point of aim adjustment. Every 10 clicks on the turret will measure exactly 1 mil spacing , also known as 1 MRAD. Because of FFP this is true on all magnifications.
HAWKE AIRMAX 30 COMPACT
Wide Angle optical system ideal for varmint/airgun
Lightweight and compact construction – short eye relief
16 layer fully multi-coated optics for exceptional clarity
Side focus control for parallax adjustment to infinity
30mm mono-tube chassis for superior strength
Glass etched reticle with red illumination
6 levels of brightness with off positions in-between
1⁄10 MRAD capped, resettable target turrets
Fast focus eyebell and high torque zoom ring
HAWKE AIRMAX 30 COMPACT
Wide Angle optical system ideal for varmint/airgun
Lightweight and compact construction – short eye relief
16 layer fully multi-coated optics for exceptional clarity
Side focus control for parallax adjustment to infinity
30mm mono-tube chassis for superior strength
Glass etched reticle with red illumination
6 levels of brightness with off positions in-between
1⁄10 MRAD capped, resettable target turrets
Fast focus eyebell and high torque zoom ring
HAWKE AIRMAX 30 COMPACT
Wide Angle optical system ideal for varmint/airgun
Lightweight and compact construction – short eye relief
16 layer fully multi-coated optics for exceptional clarity
Side focus control for parallax adjustment to infinity
30mm mono-tube chassis for superior strength
Glass etched reticle with red illumination
6 levels of brightness with off positions in-between
1⁄10 MRAD capped, resettable target turrets
Fast focus eyebell and high torque zoom ring
HAWKE AIRMAX 30 SF 8-32X50
The Hawke Airmax 30 SF family of scopes focusses on long and short range Airgun hunting and Airgun Target shooting. " 16 layer fully multi-coated optics for exceptional clarity " Side focus control for parallax adjustment to infinity " 30mm mono-tube chassis for superior strength " Glass etched reticle with red illumination " ¼ MOA exposed, locking and resettable turrets " Fast focus eyebell and high torque zoom ring Product Code: 13340
HAWKE AIRMAX 30 WA SF 6-24X50
pecialist scopes designed by airgunners for airgunners!
Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.
•Capped Target Turrets
•30mm Mono-tube chassis
•Wide Angle
•Side Focus
•Illumination
•16 layer Fully Multi-Coated lenses
•High torque zoom ring
•Fast focus eyebell
•AMX reticle designed for airguns
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
Model: 13 321
Bar Code: 5054492133215
Brand: Hawke
Product Type: Riflescope
Product Range: Airmax
Magnification: 6-24
Scope Tube ∅: 30mm
Reticle: AMX IR
Optical System: System H2
Objective Lens: 50mm
Parallax: Side Focus
HAWKE AIRMAX 4-12X40 AO AMX
Capped Low-Profile Turrets
1 Inch Mono-tube chassis
Wide Angle
16 layer Fully Multi-Coated lenses
High torque zoom ring
Fast focus eyebell
AMX reticle designed for airguns
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
AMX Reticle
Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.
Half Mil Dot spacing on the lower post provides increased aim points for long shots.
The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.
HAWKE FRONTIER 3-15X44 IR SF
21 layer Fully Multi-Coated 5× ratio optical system Side focus control for parallax adjustment 1″ mono-tube chassis for superior strength Long eye relief for high recoil and magnum calibres Glass etched reticle with red illumination 6 levels of brightness with off positions in-between 1⁄10 MRAD exposed Zero Lock 'n' Stop turrets Zoom ring with thumb lever and locking ocular
HAWKE FRONTIER 4-20X44 IR SF
21 layer Fully Multi-Coated 5× ratio optical system
Side focus control for parallax adjustment
1″ mono-tube chassis for superior strength
Long eye relief for high recoil and magnum calibres
Glass etched reticle with red illumination
6 levels of brightness with off positions in-between
1⁄10 MRAD exposed Zero Lock 'n' Stop turrets
Zoom ring with thumb lever and locking ocular
HAWKE PANORAMA 3-9X40
A revelation in optical design. An optical system with a field of view 30% wider than normal. A one inch tube 20% lighter than normal. Lighter and brighter. We call it Panorama.
Features:
• 16 layer fully multi-coated optics for exceptional clarity
• Wide view optical system ideal for varmint/airgun
• Glass etched reticle with red and blue illumination
• Rheostat on saddle offers 5 levels of brightness
• 1 inch mono-tube chassis for superior strength
• ¼ MOA low profile no-snag fingertip turrets
• Fast focus eyebell and high torque zoom ring
• Threaded objective/ocular for optional accessories
Reticule information:
10× ½ Mil Dot Reticle
Accurate mil spacing on 10×. Features dots and ties at half mil spacing, ensuring that there is always an aim point available. Glass etched fully floating reticle.
One of the additional benefits of the 10x Half Mil Dot is the mil spacing and 0.2 mil spacing segments of the hollow bars which can be used to accurately range find targets.
HAWKE PANORAMA 4-12X40
Hawke Panorama 4-12x40
The performance and design that make the Endurance scopes so popular is mirrored in the Panorama riflescope family. A compact turret design and an inset rubber magnification ring keep the profile of the scope minimal, while maintaining functionality. Where the Panorama stands apart is in the way the optical system has been designed to maximise your field of view. Panorama scopes offer a wider field of view over the Endurance range.
Features:
" 16 layer fully multi-coated optics for exceptional clarity
" Wide view optical system ideal for varmint/airgun
" Glass etched reticle with red and blue illumination
" Rheostat on saddle offers 5 levels of brightness
" 1 inch mono-tube chassis for superior strength
" ¼ MOA low profile 'no-snag' fingertip turrets
" Fast focus eyebell and high torque zoom ring
" Threaded objective/ocular for optional accessories
Product Code:15120
